AKH-0.66K series of open-type current transformers are mainly used in the transformation projects of the urban and rural power grids. It is easy to install, does not need to dismantle the bus bar, and can also be operated with electricity. It does not affect the normal electricity consumption of customers and saves manpower for the user's transformation projects. , Material and financial resources, improve efficiency. This series of current transformers can be used in conjunction with relay protection, measurement, and metering devices.
Type | Dimension(mm) | Dia. (mm) | Error(mm) | ||||||
W | H | D | M | N | Φ1 | Φ2 | |||
K-Φ10 | 27 | 44 | 32 | 25 | 36 | 10 | 9 | ±1 | |
K-Φ16 | 31 | 50 | 36 | 27 | 42 | 16 | 17 | ||
K-Φ24 | 39 | 70.5 | 55 | 36 | 52 | 24.5 | 23 | ||
K-Φ36 | 42 | 81.5 | 66 | 40 | 55.5 | 33 | 35 | ||
K-Φ24 | 39 | 70.5 | 55 | 36 | 52 | 24.5 | 23 | ±1 | |
K-Φ36 | 42 | 81.5 | 66 | 40 | 55.5 | 33 | 35 | ||
K-Φ50 | 46.5 | 110 | 90 | 54 | 66.5 | 47 | 52 |
